NMR Log Interpretation Workbook: T2 Distribution, BVI/FFI & Coates Permeability
Interpret NMR T2 distributions: partition clay-bound, capillary-bound (BVI) and free-fluid (FFI) porosity, estimate permeability with Coates and SDR models, and QC against conventional porosity.
TAGLINE
Interpret NMR T2 distributions: partition clay-bound, capillary-bound (BVI) and free-fluid (FFI) porosity, estimate permeability with Coates and SDR models, and QC against conventional porosity.
WHO IT'S FOR
Formation evaluation engineers and petrophysicists interpreting NMR logs for porosity partitioning and permeability estimation.
WHAT IT DOES
Accepts T2 bin amplitudes, applies clay-bound and capillary-bound cutoffs, calculates Coates, Timur and SDR permeability (SDR from the log-mean T2), and builds a depth-log summary. NMR porosity comes from the scaled amplitudes, so the QC against conventional porosity is a real comparison.
TABS INCLUDED (11)
• Instructions & Legend • Assumptions — T2 cutoffs and model constants • T2 Input — bin amplitudes with cumulative • Porosity Partition — CBW / BVI / FFI, effective porosity, T2 log mean • Permeability Estimates — Coates, Timur, SDR • Depth Log — station summary • Porosity QC Crossplot — NMR vs conventional with 1:1 • BVI vs FFI Crossplot — partition by station • Permeability QC Crossplot — Coates vs SDR k • BVI FFI Bar Chart — partition summary • Summary & QC
KEY FORMULAS
BVI = amplitude between the clay-bound and T2 cutoffs; Coates k = 10⁴·φe⁴·(FFI/BVI)²; SDR k = 4·φ⁴·T2LM²; T2LM = exp(Σ amp·ln T2 / Σ amp)
TECHNICAL SPECS
• Excel 2016+; 390+ formulas; 11-bin T2 sample; crossplots & charts included • MDT professional color scheme throughout • Yellow cells = inputs; white cells = formulas
ABOUT RESERVOIR RISK SOLUTIONS
Built by petroleum engineers for petroleum engineers. All workbooks require only Microsoft Excel (2016+) — no plugins, no subscriptions. www.reservoir-risk-solutions.com
